Componentes principais
Codigo | Contator | Rele de sobrecarga | Disjuntor | Tamanho da caixa |
995001 | 12A | 4-6,3A | 16A | 200X140X140MM |
1029301 | 12A | 5,5-8A | 16A | 200X140X140MM |
1029401 | 18A | 7-10A | 20A | 200X140X140MM |
1029501 | 25A | 9-13A | 25A | 200X140X140MM |
1029601 | 25A | 12-18A | 32A | 200X140X140MM |
1029701 | 32A | 12-18A | 40A | 200X140X140MM |
1029901 | 12A | 1,6-2,5A | 10A | 280X180X140MM |
1030001 | 12A | 2,5-4A | 10A | 280X180X140MM |
1030101 | 12A | 2,5-4A | 10A | 280X180X140MM |
1030201 | 12A | 4-6A | 16A | 280X180X140MM |
1030301 | 18A | 7-10A | 16A | 280X180X140MM |
1030401 | 18A | 9-13A | 20A | 280X180X140MM |
1030501 | 25A | 9-13A | 25A | 280X180X140MM |
1030601 | 32A | 12-18A | 40A | 280X180X140MM |
1030701 | 40A | 17-25A | 50A | 280X180X140MM |
1030801 | 65A | 23-32A | 70A | 280X180X140MM |
1030901 | 12A | 1-1,6A | 10A | 280X180X140MM |
1031001 | 12A | 1,6-2,5A | 10A | 280X180X140MM |
1031101 | 12A | 1,6-2,5A | 10A | 280X180X140MM |
